Shutterbox Roller Shutter Systems
Shutterbox Roller Shutter Systems feature monoblock roller blinds that perfectly adapt to all kinds of projects which do not protrude from the facade of the building and installed on the window. Being highly aesthetic and functional and featuring various lamination options they offer suitable solutions for your architectural and decorative expectations.
Shutterbox roller shutter systems features box systems of 3 different sizes.
- 155 mm Roller Shutter Box
- 195 mm Roller Shutter Box
- 220 mm Roller Shutter Box
Featuring 3 different box sizes, Shutterbox Roller Shutter Systems are designed to be compatible with all Fıratpen window and door sizes from the largest openings to the smallest ones.
Shutterbox Roller Shutter Systems can accommodate PVC or aluminum slats from 37 mm to 55 mm.
The system is designed to fit the sliding systems as well as roller blinds and pleated fly nets thanks to the detail profiles.
The motors integrated inside the casing makes it possible to operate the Shutterbox roller shutter systems by pressing a button control or using the remote controller.
Shutterbox rolling shutter systems add value to the building they are applied thanks to the heat and sound insulation they offer and additional burglary protection.
- 155 mm Roller Shutter Box
- 195 mm Roller Shutter Box
- 220 mm Roller Shutter Box
General Features of Roller Shutter Systems
- Roller shutter casings consist of only 2 different profiles.
- The pins located on the side cover and on center bearings assure error-free and easy installation.
- All 3 box profiles have common center rail and side rails.
- It is suitable to apply different colors inside and outside thanks to its two-piece outer cover.
- Special aluminum slats developed to improve resistance of the shutter casings against sunlight are available.
- The detail profiles ensure that sliding systems and fly net systems can be used in integration with the roller shutter system.
Roller Shutter Systems Box Winding Dimensions
220 mm Roller Shutter Box
| Slat Type |
Drum Type (mm) |
Max. Winding Height (mm) |
Recommended Max. Width (mm) |
|---|---|---|---|
| 37 mm PVC | 40 | 4,000 | 1,200 |
| 60 | 4,000 | ||
| 52 mm PVC | 60 | 2,800 | 1,500 |
| 39 mm Alum. | 40 | 4,000 | 2,000 |
| 60 | 4,000 | ||
| 41 mm Alum. | 40 | 3,250 | 2,000 |
| 60 | 3,250 | ||
| 45 mm Alum. | 40 | 3,250 | 2,000 |
| 60 | 3,250 | ||
| 55 mm Alum. | 60 | 2,000 | 2,200 |
195 mm Roller Shutter Box
| Slat Type |
Drum Type (mm) |
Max. Winding Height (mm) |
Recommended Max. Width (mm) |
|---|---|---|---|
| 37 mm PVC | 40 | 3,000 | 1,200 |
| 60 | 2,900 | ||
| 52 mm PVC | 60 | 2,000 | 1,500 |
| 39 mm Alum. | 40 | 3,000 | 2,000 |
| 60 | 2,700 | ||
| 41 mm Alum. | 40 | 2,200 | 2,000 |
| 60 | 2,000 | ||
| 45 mm Alum. | 40 | 2,000 | 2,000 |
| 60 | 2,000 | ||
| 55 mm Alum. | 60 | 1,750 | 2,200 |
